Which foundation does it use?

A slab plan and a crawlspace plan are both drawn. Pick one for your build; you do not need both.

Is the loft a bedroom?

The loft is drawn as an open loft reached by a straight stair from the main room. Whether it can be used or counted as a bedroom depends on your local code, including egress rules. Confirm with your building official.

Is the ridge beam size final?

No. The 6x12 ridge beam, its posts and footings are drawn at assumed sizes. Have a licensed professional verify the sizes, spans and bearing for your site before you build.

Is the porch covered?

Yes. The 24' x 10' front porch is drawn under a shed roof on four posts, reached through a 6'-0" French door pair.

Is a material list included?

No. This set has the sheets listed above and no material list.

No. The download is PDF sheets only.

Can I change the plan for my build?

Yes. The license lets you modify the plans for your one build. See the license page for the full terms.

The Summit 24x40 Two-Bedroom Loft Cabin Plan

Plan SPS-CA-2440-01

First floor plan, low-resolution preview

Preview images are made from this plan's own drawings: low resolution, watermarked. They are line drawings, not photos or renderings.

Heated area: 1,156 sq ft (960 first floor + 196 loft)
Footprint: 24' x 40'
Bedrooms: 2
Bathrooms: 2
Stories: 1 + loft
Covered porch: 24' x 10'
Roof: Gable, 10/12
Foundations: Slab or crawlspace (both drawn)

About this plan

The Summit is a 24'-0" x 40'-0" one-story cabin with a loft. It has 1,156 sq ft heated: 960 sq ft on the first floor plus 196 sq ft of loft with 5'-0" or more headroom. A 24'-0" x 10'-0" covered porch runs across the front, reached through a 6'-0" French door pair.

The living room, dining room and kitchen share a vaulted ceiling under a 10/12 gable roof. The primary bedroom (9'-6 1/2" x 9'-11 1/2") has its own bath with a 36" x 36" shower and a walk-in closet. Bedroom 2 (9'-4" x 7'-1") has a reach-in closet and uses the hall bath, which has a 60" tub and a stacked washer-dryer. The bedroom wing has 8'-0" ceilings, with the 12'-5 1/2" x 15'-8 1/2" loft above, reached by a straight stair.

This is a concept / pre-design plan set. Slab and crawlspace foundations are both drawn; pick one for your build. A licensed architect or engineer where you build must review, adapt and stamp the plans before permit or construction. Have a licensed professional verify the ridge beam.

What's included with this plan

What's included

3 sheets. Digital PDF.

Cover sheet
Slab foundation plan, notes, floor plan and front elevation
Crawlspace foundation plan, loft plan and elevations

No material list is included with this plan. Get quotes from your builder or supplier against your final, locally reviewed plans.

Not included

Stamp or seal of any kind
Site plan
Structural calculations
Electrical plan
Material list
Roof framing plan
Changes for your local code
CAD files

Who drew this plan

Drawn by Small Plan Shop and checked against our review checklist. Items to confirm with your local builder or engineer are listed on the plan sheets.

About Small Plan Shop

Before you permit or build

Concept / pre-design plan. Not for construction. A licensed architect or engineer in your area must review, adapt and stamp before permit or construction.

Concept / pre-design plans. Drawn with reference to the 2021 IRC as a general guide only. They carry no professional seal and are not designed for your specific site. Codes vary by location. A licensed architect or engineer where you'll build must review, adapt and stamp the plans, and confirm local codes, before permitting or construction. The buyer is responsible for permits, site work and foundation design. Small Plan Shop is not responsible for construction without that review. Full disclaimer.

License and refunds

One build, one site, not transferable. See the full license.

Refunds: Digital plans are final sale. If a file is broken or a listed sheet is missing, we fix it or refund you.

Questions about this plan

Does the plan carry a stamp or seal?: No. It is a concept / pre-design plan set with no stamp or seal. A licensed architect or engineer where you build must review, adapt and stamp it before you apply for a permit or build.
Which foundation does it use?: A slab plan and a crawlspace plan are both drawn. Pick one for your build; you do not need both.
Is the loft a bedroom?: The loft is drawn as an open loft reached by a straight stair from the main room. Whether it can be used or counted as a bedroom depends on your local code, including egress rules. Confirm with your building official.
Is the ridge beam size final?: No. The 6x12 ridge beam, its posts and footings are drawn at assumed sizes. Have a licensed professional verify the sizes, spans and bearing for your site before you build.
Is the porch covered?: Yes. The 24' x 10' front porch is drawn under a shed roof on four posts, reached through a 6'-0" French door pair.
Is a material list included?: No. This set has the sheets listed above and no material list.
Do I get CAD files?: No. The download is PDF sheets only.
Can I change the plan for my build?: Yes. The license lets you modify the plans for your one build. See the license page for the full terms.

Questions? Email [email protected], or write to Small Plan Shop, PO Box 271, Lincoln, AL 35096.
