The Laurel 24x28 Loft Cabin Plan with Full Basement

Plan SPS-CA-2428-01

First floor plan, low-resolution preview

Preview images are made from this plan's own drawings: low resolution, watermarked. They are line drawings, not photos or renderings.

Heated area: 838 sq ft (672 first floor + 166 loft)
Footprint: 24' x 28'
Bedrooms: 1 (plus a future bedroom in the basement)
Bathrooms: 1
Stories: 1 + loft, over a full basement
Covered porch: 24' x 6'
Roof: Gable, 12/12
Foundation: Full basement, unfinished (672 sq ft)

About this plan

The Laurel is a 24'-0" x 28'-0" cabin with a loft over a full basement. It has 838 sq ft heated: 672 sq ft on the first floor plus 166 sq ft of loft with 5'-0" or more headroom. A 24'-0" x 6'-0" covered porch runs across the front.

The living room, dining area and kitchen share a vaulted ceiling under a 12/12 gable roof. One bedroom (10'-4" x 9'-4"), a bath with a tub, a laundry and a storage room sit on the north side under an 8'-0" ceiling. The loft is reached by a straight stair from the living room, with the basement stair below it.

The unfinished basement has a family room, a future second bedroom with an egress window and well, and a mechanical and storage room.

This is a concept / pre-design plan set. A licensed architect or engineer where you build must review, adapt and stamp the plans before permit or construction. Have a licensed professional verify the ridge beam and basement girder.

What's included with this plan

What's included

4 sheets. Digital PDF.

Cover sheet
First floor plan, front elevation and notes
Basement plan, loft plan and foundation notes
Building sections and elevations

No material list is included with this plan. Get quotes from your builder or supplier against your final, locally reviewed plans.

Not included

Stamp or seal of any kind
Site plan
Structural calculations
Electrical plan
Material list
Roof framing plan
Changes for your local code
CAD files

Who drew this plan

Drawn by Small Plan Shop and checked against our review checklist. Items to confirm with your local builder or engineer are listed on the plan sheets.

About Small Plan Shop

Before you permit or build

Concept / pre-design plan. Not for construction. A licensed architect or engineer in your area must review, adapt and stamp before permit or construction.

Concept / pre-design plans. Drawn with reference to the 2021 IRC as a general guide only. They carry no professional seal and are not designed for your specific site. Codes vary by location. A licensed architect or engineer where you'll build must review, adapt and stamp the plans, and confirm local codes, before permitting or construction. The buyer is responsible for permits, site work and foundation design. Small Plan Shop is not responsible for construction without that review. Full disclaimer.

License and refunds

One build, one site, not transferable. See the full license.

Refunds: Digital plans are final sale. If a file is broken or a listed sheet is missing, we fix it or refund you.

Questions about this plan

Does the plan carry a stamp or seal?: No. It is a concept / pre-design plan set with no stamp or seal. A licensed architect or engineer where you build must review, adapt and stamp it before you apply for a permit or build.
Which foundation does it use?: A full basement is drawn. There is no slab or crawlspace version in this set.
Is the basement finished?: No. The basement is drawn unfinished, with a family room, a future second bedroom with an egress window and well, and a mechanical and storage room. Finishing it is up to you and your local code.
Is the loft a bedroom?: The loft is drawn as an open loft reached by a straight stair from the living room. Whether it can be used or counted as a bedroom depends on your local code, including egress rules. Confirm with your building official.
Are the beam and girder sizes final?: No. The ridge beam and the basement girder are drawn at assumed sizes. Have a licensed professional verify the sizes, spans and bearing for your site before you build.
Is a material list included?: No. This set has the sheets listed above and no material list.
Do I get CAD files?: No. The download is PDF sheets only.
Can I change the plan for my build?: Yes. The license lets you modify the plans for your one build. See the license page for the full terms.
